Meter hardware datasheet & comparisons

When you become a Meter Network customer, your space is equipped with Meter Hardware, including our controllers and access points. We manufacture our own hardware to provide the best security and reliability of the network. All of the hardware and free upgrades are included in your monthly rate, so you don’t have to worry about paying any up-front costs or making trade-offs for optimal performance.

While the hardware that Meter uses is critical towards the goal of providing fast, reliable, and safe internet, the Meter difference lies in our software that we integrate into the physical network.

Meter Controller/Router

Meter Controller

The Meter Controller is the heart of your network, enabling wired and wireless clients to access the local network and the internet. It acts as the DHCP/DNS/Gateway for the Meter Wireless Access Points. We typically install 1 controller per site.

Specifications
Meter Controller
CPU
2.2GHz 2-core
2.2GHz 4-core
Memory
4GB/ 8GB DDR4
Hdd
64GB / 128GB SSD
Network
6 x GbE RJ45
2 x GbE (SFP)
LTE
Case
19" 1U rack mount
Power
AC/DC 100-240V, 60W
Power Consumption
15W (idle)
LEDs
Status, Speed/Link/Activity

Meter Wireless Access Points

Meter Wireless Access Point MW02

The Meter Wireless Access Points (APs) contain radios that transmit data to devices. Each AP is equipped with 2 radios (2.4GHz, 5GHz frequencies); the majority of devices run on 5GHz, while 2.4GHz is legacy. The number of APs we install varies based on size of the office space and other space considerations (i.e., building materials, large conference rooms, etc.).

Specifications
Meter Wireless
MW02
Radios
Dual concurrent radios
2.4 GHz 3x3 MIMO 5 GHz 4x4 MIMO
2.4 GHz Radio rate
450 Mbps
5 GHz Radio rate
1750 Mbps
WiFi
Dual Band
802.11 a/b/g/n/ac
Max Tx Power
2.4 GHz: 23 dBm
5 GHz: 27 dBm
Power
802.3at PoE, 48V 0.5A

Meter Wireless Access Points vs. others

Meter hardware is best-in-class and uses the same manufacturing partners as comparable hardware vendors.


Meter Wireless Access Point MW03
Cisco Meraki MR52
Ubiquiti UAP-AC-HD
Meter Wireless Access Point MW02

Meter Wireless
MW03
Cisco Meraki
MR52
Ubiquiti
UAP-AC-HD
Meter Wireless
MW02
CPU
IPQ8064;
1.4G Dual-Core
IPQ8068;
1.4G Dual-Core
IPQ806x;
1.4G Dual-Core
QCA9558;
720MHz
RAM
256MB
Not disclosed
512MB
256MB
Flash
32MB NOR
+ 256MB Nand
Not disclosed
32MB Flash
16MB NOR
WiFi Standards
802.11ac,
Backwards compatible
802.11ac,
Backwards compatible
802.11ac,
Backwards compatible
802.11ac,
Backwards compatible
WiFi Spectral Bands
2.4GHz + 5GHz
2.4GHz + 5GHz
2.4GHz + 5GHz
2.4GHz + 5GHz
WLAN Hardware
(2.4GHz + 5GHz)
QCA9985+ QCA9984
QCA9994 + QCA9889
QCA9994 + QCA9994
AR9550 + QCA9984
Data Rates

(2.4 GHz + 5GHz)
800 Mbps
+ 1733 Mbps
800 Mbps
+ 1733 Mbps
800 Mbps
+ 1733 Mbps
450 Mbps
+ 1733 Mbps
Radio Chains /
Spatial Streams
4x4:4
4x4:4
4x4:4
3x3:3 (2.4GHz);
4x4:4 (5GHz)
Power Supply
802.3at PoE+;
25W
802.3at PoE+;
25W
802.3at PoE+;
25W
802.3at PoE+;
25W
